10.1'' Lcd Touch Screen 1280x800 Controller Board FOR Machine Display DIY KIT

$ 54.67

Outline Dim.: 228.21x148.86 mm Compatible Brand: Universal gtin13: Does not apply Product Type: Panel LCD Combo Model Number: 10.1 inch tft IPS lcd display 1280x800 Signal Type: LVDS (1 ch,8-bit),45 pins Connector Aspect Ratio: 16:10 Brand: Wisecoco Display Area: 216.96x135.6 mm Display Size: 10.1 Inch Pixel Format: 1280(RGB)x800,WXGA UPC: Does not apply Screen Type: IPS Interface Type: HDMI,VGA Brightness: 450 cd/m² Origin: Mainland China Viewing Angle: 89/89/89/89

Description

Wisecoco 10.1 In ch Tft Lcd Module Capacitive Touch Screen 1280x800 HDMI Controller Board Panel Automatic Ticket Vending Machine Display DIY KIT General Features : Panel Size: 10.1 inch Panel Type: LCM, a-Si TFT-LCD Resolution: 1280(RGB)x800 (WXGA) Display Area: 216.96 x 135.6 (HxV) mm Outline Size: 228.21 x 148.86 x 4. 59 (HxVxD) mm Bezel Area: 218.56 x 137.2 (HxV) mm Brightness: 450 cd/m² (Typ.) Contrast Ratio: 900:1 (Typ.) (TM) Viewing Angle: 89/89/89/89 (Typ )(CR210) Best View on: Symmetry Display Colors: 16.2M 50% NTSC Lamp Type: 4 strings WL ED，No Driver Response Time: 30 (Typ.)(Tr+Td) ms Work Mode PLS, Normally Black, Transmissive Refresh Rate: 60Hz Touch Screen: Available , 10 Points capacitive touch panel Application: Pad, Tablet etc. Signal Interface: LVDS (1 ch, 8-bit) ，45 pins Connector lInput Voltage: DC 12V/2A Storage Temp: -20 ~ 60 °C Operating Temp: 0~ 50 °C
