12-18V Power Module 300V Capacitor Capacitor Negative Insulation Inverter Board
$ 4.21
Description
12-18V Power Module 300V Capacitor Capacitor Negative Insulation Inverter Board DESCRIPTION Features: Pin Definition: 1-Pin Yellow Wire:DRAIN,power control port.connect with MOS power tube D pole (usually is power switch tube middle pin) 2-Pin Black Or Pink Wire:GND,module ground wire 300V.connect with capacitor negative 5-Pin Green Wire:start pin,connect with 300V capacitor positive Using Method: 1.Remove original power chip (usually 8-pin) and switch tube (mos tube) 2.Check 300V capacitor 3.Check if load port is short circuit,ad board,inverter board etc 4.Connect module corresponding circuit and check if there is false connection 5.Install it in origial heat sink position,pay attention to insulation,no short circuit 6.Power on,test whether voltage is output or not.please check out the reason if there is no output. Specifications: *Product Name:12-18V LCD Power Supply Board Module *Material:abs *Size:5*5*3cm *Color:as show 1. Before using this module, please first check the cold side there is no short circuit, a short circuit of the first maintenance, if the capacitor drum package, please replace the first, high-voltage package circuit is also the first short circuit, not on the module before , Remove the original module power chip and mos tube, this time the original switch tube in the middle of the electrode to the hot ground voltage to have about 300v voltage. 2. Optocoupler 3 feet if not connected to the ground, please put 3 feet heat, while the 4 feet of the external circuit demolition, and the white line received 4 feet Package Content: 1 x 12-18V LCD Power Supply Board Module Note : 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data. POLICES Shipping Payment WARRANTY We only ship to confirmed ebay Order addresses. Please comfirm that your Order address is in line with your shipping address. Please kindly note that the c ombined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7 -15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection . If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, p lease feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours. On Oct 24, 2024 at 03:52:48 PDT, seller added the following information:
