2 HP SPL Compressor Duty Electric Motor 3450 RPM 56 Frame 5/8" Shaft 115/230V US

$ 69.46

Part Type:: 2 Hp Air Compressor Shaft Diameter: 5/8" Keyed shaft Horsepower: 2HP Shipping Note: Cannot ship to Puerto Rico & Hawaii RPM: 3450 MPN: Does Not Apply Service Factor: 1.0 Color: Black Shaft Length: 1.88" Suitable For: Air Compressor Applications Current Type: AC Rotation: CCW WHEN VIEWED FROM SHAFT END Feature 2: High Quality with Warranty INS.CL: F UPC: Does not apply Enclosure Type: ODP (Open Drip-Proof) AC Frequency Rating: 60 Hz NEMA Frame Suffix: N/A Phase: One / Single Phase AC Phase: Single Phase gtin13: Does not apply Surface Finish 1: Made of high quality material Amperage: (7.5 FLA @ 240V) (15 FLA AT 115V) IEC Frame Size: N/A Special Motor Construction: N/A Model: Suitable For: Air Compressor Applications Overload: Yes / Manual reset button Reversible/Non-Reversible: Non-Reversible Full Load Amps: 15/7.5 Frame: 56 Duty: Cont. Compressor Nominal Rated Input Voltage: N/A AC Motor Type: N/A 1.Feature: High-quality Rated Load (HP): 2 Brand: Unbranded Country/Region of Manufacture: Unknown Shaft Type: Keyed Voltage: 115/230V (NOT SUITED FOR 208V INCOMING)

Description

Air Compressor Electric Motor 2 HP 56 Frame Single Phase 120/240 Volt 3450 RPM Product Function Description: Specifications: • Open Drip Proof (ODP) Enclosure • Single Phase • 2 HP • 3450 RPM • 60hz • 120/240 Volts • AMB 40 °C • Frame: 56 • Duty: Cont. Compressor • Service Factor: 1.0 • Full Load Amps: 15/7.5 • INS.CL: F • Non-Reversible, CCW Rotation Facing Shaft • Thermally Protected • Overall Height: 8.5" • Overall Width: 6.35" • Shaft Diameter: 5/8" • Shaft Length: 1.88" • Standard Size Keyway: 3/16" • Features Manual Reset Overload Protection Key Features: • Here we offer you our brand new Air Compressor Duty Electric Motor • High quality Material Steel • High Starting Torque • Rigid Base • Lubricated with Low Temperature grease • Able to withstand harsh industrial applications. • Powerful Ac Motor • Totally Enclosed Fan • Manual Overload Protection • Mounting Bracket Included • 2 HP SPL 3450 RPM, 56 Frame , 120/240V, 15/7.5Amp 5/8" Shaft, Single Phase Air Compressor Electric Motor • Open dripproof Single phase Full Load amps: 15/7.5Amp, 120/240V 2 HP SPL 3450 RPM 5/8 Shaft • Reduced starting amperage design to ensure the reduced voltage starting at rated load. • Equipped with UL approved Manual thermal overload, capacitors and high quality ball bearings to ensure the lifetime. • Open drip-proof is better used in environment that are relatively clean and dry environments. Special design for Air Compressor duty. CCW only. • Special design for Air Compressor duty. • Motor is Non-Reversible CCW (Counter Clockwise) ONLY. • Default settings are default low-voltage current. If the need to use high-voltage current, please replace the use of high voltage wiring. Package includes: 1*2 HP SPL Compressor Duty Electric Motor
