2pcs 1970 Soviet NOS 6C4P Rectifier Tubes Equivalent to 6Z4 EZ90 6Z31

$ 4.23

Country/Region of Manufacture: Russian Federation Brand: Soviet Type: Rectifier Tubes Model: 6C4P MPN: 6C4P gtin13: Does not apply UPC: Does not apply

Description

2pcs 6C4P = 6Z4, EZ90, 6Z31 Rectifier Tube Reflector Soviet SAME YEAR 1970 NOS Ich verkaufe 8 Stück 6C4P (6Ц4П) Röhren NEU NOS I am selling 8 pcs. 6C4P tubes NEW NOS Name: 6C4P / 6Ц4П Analogue: EZ90, 6Z31, 6Z4 Manufacturer: Reflector factory Condition: NOS (new from old stock), never used Date of manufacture: 1990'S The tube 6C4P is a direct replacement for 6Z4 (China) tube, but have a different pinout for EZ90/6Z31. Kenotron 6C4P low-voltage two-anode high durability, reliability and mechanical strength. It is intended for rectification of alternating current of industrial frequency of 50Hz. Works in any position. E - characterizing the increased durability of the tube; V - tube with increased reliability and mechanical strength. Military acceptance stamp " B☆П " Stamp of technical control department of the manufacturer " ОТК " Technical specifications: Filament voltage: 6.3 ± 0.3V Filament current: 450 ± 45mA Anode voltage reverse limit: (peak value) 900V Anode current limit: (peak value) 300mA Rectified current rated: not less than 68mA Rectified current limit: 75mA Power dissipated by the anode: limit 3W The voltage between the cathode and the heater: limit (constant) 400V Voltage of the secondary winding of the transformer: 2 x 350V Resistance in the cathode circuit: 5.2KOhm Filter capacitance: 8uF Durability not less than 5000h --------------------------------------------------------------------------------------------------------------------------------------------------- Import duties, taxes and chargers are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding buying. Combine shipping is accepted. If you need less or more items of this type, or if you need add some other items, contact us, and we will make special listing for you. Give us the list of items you need, and we'll do the rest. We have many other vacuum tubes for audio and other, ask us if you need any of them. Items are shipped from Lithuania Post (Europe Union) via expedited International tracking. Returns We guarantee you complete satisfaction with all our high quality products. If you receive an item you did not order, or if an item you ordered is received damaged or defective, we will refund you the price you paid for it or replace it with identical one. The item should come to the above address within 30 days after you received it. After 30 days we will no longer be responsible and the item won't be taken back. Item for returning must have the original tags and packing, otherwise it won't be accepted.
