Direct Current Photoelectric Switch,DC8-50V Light Control Switch Dusk to Dawn...
$ 10.76
Description
Specification: Condiiton: 100% Brand New Shell material: PC Color: Black Wiring: Export three-wire system Voltage range: 12V 24V 36V 48V Supply voltage: 8V to 50VDC (module normal operating voltage range) Standby current: 0.5ma (silent state) Output power: High power, load current 5A, the pressure drop is negligible. Power consumption: 0.6Wmax Anti interference delay: about 0.6 second Sensitivity: 5-10LX on 30-60LX off Environment temperature: -40℃ ~ +70℃ Related Humidity: 99% RH Working Life: 10000 cycles Detector waterproof : IP 65 Use of the environment, temperature: Can not be installed in a corrosive gas environment, minus 25 to 70 degrees. Leads Length: 150mm Product Size: (L) x (W) x(H) 40 x 15.6 x 20 mm / 1.57" x 0.61" x 0.79"(appr.) Package Included: 2x Photocell Switch 【Automatically On/ Off】 The internal environment of the dusk to dawn switch is equipped with automatic illumination detection circuit, which will shut down during the day and open during the night automatically, control the lighting time according to the brightness of the environment, bringing much convenience for your daily life 【Automatic DC 12V 24V 36V 48V Photocell Switch For Outdoor Lights】 The photocell switch has a wide voltage input range from DC 8V to 50V, loading 5A, power supply voltage of 12V 24V 36V 48V 【Waterproof And Safety】Photocell Switch with a waterproof cover to protect elements, matching waterproof washer, dustproof and waterproof, suitable for commercial or residential outdoor fixtures. 【Wide Applications】Fits to automatic switching control of solar Led lights, stree lamps, courtyard lamps, corridor lamps and other lighting fixtures; or cars, motorcycles, cars, golf cart, club car and other power supply voltage is 12V 24V 36V 48V lamps and lanterns or equipment. 【NOTE!】 The light control switch adopt 3 wire system, with resistance; The white line is positive input（+）, the black line is negative input(-); White line and red line for load (Output), white line is common line; Please reading the wiring method before installing; If the installation is reversed, the switch will be short circuit instantly; Specific instruction please refer to the picture
