HD-C16 Full Color LED Screen Wi-Fi Control Card Support
$ 114.71
Description
Controller Features: Control Range: (HD-C16/C16C) 122,880 pixels, HD-C36/C36C 524,288 pixels 4GB memory, support expending memory by U-disk. Support HD video hardware decoding, 60Hz frame rate output. Support widest 8192 pixel, (HD-C16/C16C) Highest 512, (HD-C36/C36C) Highest 1024. No need set IP address, it could be identified by controller ID automatically. Unified management of more LED display through Internet or LAN. Equipped with Wi-Fi function, Mobile APP management directly. Equipped with 3.5mm standard audio interface output. Meanwhile support to add 4G networking module connect to Internet (Optional). Equipped with (HD-C16/C16C)2 lines 50PIN HUB port, (HD-C36/C36C)10 lines HUB75E port, can be used for one receiving card. Equipped with 1 group of relay module, support switch on/off power supply directly remotely. Controlling System Configuration Product Type Functions Async controller Card HD-C16/C36 Asynchronous core control panel, with storage capabilities, can be connected to the screen modules, with 2 lines 50PIN HUB port. HD-C16C/C36C Asynchronous core control panel, with storage capabilities, can be connected to the screen modules, with 10 lines HUB75E port. Receiving Card R Series Connected with screen, Showing program in Screen. Control Software HDPlayer Screen parameters setting, edit & send program etc. Note: Supported computer software HDPlayer, mobile phone control software LedArt and HD Cloud Platform. Control Mode: 1. Internet unified management: The play box can be connected to the Internet through 4G (optional), network cable connection, or Wi-Fi Bridge. 2. Asynchronous one-to-one control: Update programs by network cable connections, Wi-Fi connections or USB flash drives. LAN (cluster) control can access the LAN network through by network cable connection or Wi-Fi Bridge. NOTE: HD-C16/HD-C36 match Hub board to make the screen working, If need, please buy it for this link: https://www.aliexpress.com/store/product/Hub-Transfer-board-hub75E-usage-for-huidu-full-color-led-controller-C10-C30-A30/103659_32842515318.html?spm=2114.12010612.0.0.289c972bYzjJ9E System Function List Item C16 C16C C36 C36C Module type Compatible with indoor and outdoor full color and single color module Support conventional chip and mainstream PWM chip Scan Mode Static to 1/64 scan mode Control Range 384*320, widest 8192, highest 512 1024*512, widest 8192, highest 1024 Gray Scale 256-65536 Basic functions Video, Pictures, Gif, Text, office, Clocks, Timing etc. Remote, Temperature, Humidity, Brightness etc. Video format Support 1080P HD video hardware decoding, direct transmission, without transcoding waiting. 60Hz frame frequency output； AVI, WMV, MP4, 3GP, ASF, MPG, FLV, F4V, MKV, MOV, DAT, VOB, TRP, TS, WEBM, etc. Image Format Support BMP, GIF, JPG, PNG, PBM, PGM, PPM, XPM, XBM etc. Text Text editing, Image, Word, Txt, Rtf, Html etc. Document DOC, DOCX, XLSX, XLS, PPT, PPTX etc. Office2007Document format. Time Classic Analog clock, digital clock and of clock with image background. Audio output Double track stereo audio output Memory 4GB Flash memory; Indefinite expanding of U-disk memory. Communication Ethernet LAN port, 4G network (optional), Wi-Fi, USB. Working Temperature -20℃-80℃ Port INPUTS: 5V DC*1, 100 Mbps RJ45*1, USB 2.0*1, test button*1, sensor port*1, GPS port*1. OUT:1Gbps RJ45*1, AUDIO*1 Power 8W Interface Description No. C16/C36 C16C/C36C 1 Power Supply port: connected 5V DC power supply. 2 Output network port: 1Gbps network port, connect to receiving card. 3 Input Network port: Connect to PC or router 4 Audio output port: support standard two-track stereo output 5 USB port: connected to USB device, e.g. U-disk, Mobile hard disk etc 6 Wi-Fi antenna connection port: connect with external Wi-Fi antenna. 7 4G network antenna connection port: connect with external 4G antenna 8 Wi-Fi indicator light: display Wi-Fi work status. Test button: LED screen burn-in test 9 Test button: LED screen burn-in test. 4G indicator light: display 4G network status 10 4G indicator light: display 4G network status Mini PCIE port: connect with 4G networking module for cloud control (Optional). 11 Mini PCIE port: connect with 4G networking module for cloud control (Optional). Display indicator light: working status is Flicking. 12 Display indicator light: working status is Flicking HUB75E port: connect to LED modules with flat cable. 13 HUB port: connect to HUB adapter board Reserved interface, no definition. 14 Temp sensor connection port: connect to temperature sensor and show the realtime value. 15 Relay control connection port: the power supply connection port of the relay 16 GPS port: connected GPS module. 17 Sensor port: connect S108 and S208 sensor kit. 18 Controller working state indicator light: PWR is Power lamp for status of power supply, when working normally, the lamp is always on, RUN is running lamp, when working normally, the lamp will be blinking 19 Fool-proof power interface: 5V DC power interface, with fool-proof design, with the same function as the “1” 5V DC terminal.
