Waveshare Industrial IoT 5G/4G Wireless Expansion Module for Raspberry Pi CM4

Description

DESCRIPTION Industrial IoT 5G/4G Wireless Expansion Module Designed For Raspberry Pi Compute Module 4, With UPS Module, Onboard M.2 Slot Industrial IoT Module Based On CM4 With UPS Module Suitable For IoT Applications Like IoT Getaway, Wireless Router, Intelligent Data Acquisition... 4G/5G Support, Multi Interfaces, Onboard UPS Module This is an industrial expansion module based on Raspberry Pi CM4 with UPS module, which features common interfaces such as Gigabit Ethernet, HDMI, USB, and GPIO, allows additional 4G / 5G wireless communication modules to be connected via the M.2 B KEY socket. There are also industrial interfaces/resources including RS485, CAN, and RTC. Combined with the industrial rail-mount protection case, the module is an ideal choice for building IoT gateway, 4G/5G router, IoT data acquisition, or even the PLC device in industrial automatic control system, and more. Version Upgrade Old Version CM4-IO-WIRELESS-BASE New version CM4-IO-WIRELESS-BASE-B Onboard UPS Module Part List Comparison BASIC KIT BASIC KIT + 4G MODULE CM4 wireless base board + UPS Module √ √ Black ABS case √ √ SIM7600G-H-M.2 4G module √ PCB antenna √ * please refer to Package Content for exact part list info. Specifications CM4 SOCKET suitable for all variants of Compute Module 4 UPS POWER UPS Module, 5V/2.5A (Max) output, supports 3 × 10440 lithium batteries (NOT included) NETWORKING Gigabit Ethernet RJ45 M.2 B KEY, for connecting 5G / 4G wireless module Nano-SIM card slot, supports standard Nano-SIM card for 5G/4G/3G/2G communication USB USB 2.0 × 3 PIN HEADER Non-isolated RS485 × 2, Non-isolated CAN × 1, Partial GPIO pins CAMERA MIPI CSI-2 × 1 (15pin 1.0mm FPC connector) VIDEO HDMI × 1, supports 4K 30fps output RTC Real-time clock with battery socket and ability to wake Compute Module 4 STORAGE TF card socket for Compute Module 4 Lite (without eMMC) variants FAN HEADER 5V/12V, allows speed adjustment and measurement POWER INPUT 5V or 7~36V DIMENSIONS 145 × 90 × 40mm Comparing The Expansion Boards CM4 BASE BOARD INTERFACE COUNT AND SPECIFICATIONS POE GIGABIT ETH 40PIN GPIO PCIE USB① DSI HDMI CSI RTC FAN HEADER POWER INPUT FEATURES NANO A √ 2.0×1 ×1 5V CM4 sized NANO B ×1 √ 2.0×1 ×1 ×1 ×1 5V CM4 sized NANO C √ 2.0×1 ×1 ×1 ×1 5V Onboard Camera MINI BASE A ×1 √ M.2 M 2.0×4 ×1 ×2 ×2 5V 5V mini size MINI BASE B ×1 √ M.2 M 2.0×4 ×1 ×2 ×2 √ 5V 5V mini size MINI BASE C ×1 √ M.2 M 2.0×2 ×1 ×2 √ 5V 5V Dedicated 40PIN LCD Connector TOUCH SCREEN ×1 M.2 M 2.0×4 ×1 ×1 5V IPS screen MINI DUAL GIGABIT ×2 √ 2.0×1 5V SH1.0 5V dual ETH BINOCULAR CAMERA ×1 √ M.2 M 2.0×4 ×2 5V dual 8MP cameras 4CH RS485 ×1 2.0×2 ×1 ×2 ×1 5V 7-36V dual ETH WIFI6 DUAL ETH ×1 √ M.2 E 2.0×3 ×1 ×2 ×2 ×1 5/12V 7-36V WIFI6 dual ETH DUAL GIGABIT ETH ×2 √ 3.0×3 ×1 ×2 ×2 √ 5/12V 7-36V IOT DUAL GIGABIT ETH ×2 √ 3.0×2 ×1 ×2 ×2 √ 5/12V 5V 5G/4G support IOT BASE √ ×1 Gen2×1 2.0×2 ×2 ×2 ×2 √ 5/12V 7-36V 5G/4G support RS232 RS485 ADC POE BASE (B) √ ×1 √ Gen2×1 2.0×4 ×2 ×2 ×2 √ 5/12V 5V RS232 RS485 POE UPS BASE √ ×1 √ M.2 M 2.0×4 ×1 ×2 ×2 √ 5/12V 7-36V UPS POE BASE √ ×1 √ 3.0×4 ×2 ×2 ×2 √ 5/12V 7-36V RASPBERRY PI OFFICIAL ② ×1 √ Gen2×1 2.0×4 ×2 ×2 ×2 √ 12V 12V WIRELESS BASE ×1 M.2 B / Mini-PCIe 2.0×3 ×1 ×1 √ 5/12V 5V or 7-36V 5G/4G support RS485 CAN rail-mount UPS WIRELESS BASE ×1 M.2 B 2.0×3 ×1 ×1 √ 5/12V 5V or 7-36V With UPS 5G/4G support RS485 CAN rail-mount NAS MINI COMPUTER ×2 √ M.2 M×2/ Mini-PCIe 3.0×2 ×2 ×2 √ 5V dual M.2 M KEY slots 5″ TOUCH SCREEN ② ×1 √ M.2 M 2.0×4 ×1 ×2 √ 5/12V 5V 7″ ALL-IN-ONE ×1 M.2 M 2.0×4 used ×1 used √ 5/12V used 7-36V touch screen camera speaker 13.3″ ALL-IN-ONE ×1 2.0×2 12V HD touch screen 13.3″ MAGIC MIRROR ×1 2.0×2 12V HD screen, Speech Assistant NOTE ① USB 3.0 is equivalent to USB 3.2 Gen1 ② There's PoE header only on the Raspberry Pi official IO board without PoE circuit, that means additional PoE module is required for the official IO board to enable PoE feature. Unless otherwise specified, the PoE feature here stands for integrating 802.3af-compliant PoE circuit (5V/2.5A). Connecting With Compute Module 4 Standard CM4 Socket And Partial Raspberry Pi GPIO Header Suitable For Compute Module 4 Lite/EMMC Series Module * for renference only, the CM4 and 10440 lithium batteries are NOT included 4G/5G Wireless Modules Support Onboard M.2 B KEY Slot, Compatible With 4G/5G Wireless Modules With M.2 B Connector An additional communication module is required to enable 5G/4G/3G/2G cellular network, recommended: SIM7600G-H-M.2 , SIM8202G-M2 , SIM8200EA-M2 SIM7600G-H-M.2 4G Module Optional 4G/3G/2G communication, GNSS positioning, global coverage Standard M.2 B KEY interface, high compatibility Multi-constellation high accuracy positioning GNSS receiver support Suitable for LTE, UMTS, and GSM network with global coverage Abundant software functions: FOTA, LBS, TLS, VoLTE Up to 150Mbps (Max) downlink data rate and 50Mbps (Max) uplink data rate Supports popular OS driver: Windows, Linux, Android etc. AT commands of the SIM7600G-H-M.2 series are compatible with the SIM7500/SIM7600 series modules Please refer to SIM7600G-H-M.2 product page for details For quantity of 20pcs or more, other M.2 or Mini-PCIe modules are customizable (SIM7600CE-T / E-H / A-H, etc.), feel free to contact us Rich Interfaces Reserved Space For Heat Dissipation with heatsink with cooling fan * for reference ONLY, heatsink, cooling fan and 10440 lithium batteries are NOT included. Uninterruptible Power It is able to charge the batteries and provide power output at the same time from external power supply Automatically switch over to batteries output if external power supply is unavailable, keeps the system running without any trouble Rail-Mount Support Rail-Mount ABS Protection Case, Easy To Install, Safer Operation Application Example Suitable For IoT Gateway, 4G/5G Router, IoT Data Acquisition And Monitoring, Industrial PLC, Or Other Industrial Applications. Onboard UPS Module, Keeps The System Running After Disconnecting The Power Cable for reference only, CM4, display and camera are NOT included. What's On Board CM4 socket suitable for all variants of Compute Module 4 HDMI connector supports 4K 30fps output USB 2.0 ports 3x USB 2.0, for connecting sorts of USB devices RJ45 Gigabit Ethernet 10/100/1000M compatible DC power supply 7 ~ 36V DC input CM4 status indicator PWR: Raspberry Pi power indicator ACT: Raspberry Pi operating status indicator 4G/5G module status indicator M.2 PWR: module enable indicator M.2 NET: module operating status indicator PWR & USB 5V DC power supply or USB programming port M.2 B KEY supports 4G/5G modules with M.2 B KEY connector, or other communication modules using USB channel Nano-SIM card slot supports standard Nano-SIM card for 5G/4G/3G/2G communication BOOT selection ON: CM4 will be booted from USB-C interface OFF: CM4 will be booted from eMMC or TF card UPS module ON/OFF ON: CM4 and the base board will be powered by UPS module OFF: Turn off the UPS power supply to CM4 and base board DC power supply 7 ~ 36V DC input Dual non-isolated RS485 2x RS485, with 600W lightningproof, anti-surge, and 15KV ESD protection (reserved 120R optional balancing resistor jumper) Non-isolated CAN ESD protection and transient spike voltage protection (reserved 120R optional balancing resistor jumper) TF card slot for connecting a TF card with pre-burnt image (Lite variant ONLY) FAN header for connecting cooling fan, allows speed adjustment and measurement CAM MIPI CSI camera port, 15Pin 1mm pitch RTC battery holder supports CR1220 button cell M.2 VCC selection select 3.3V or 4.2V power supply RTC interruption configuration PI-RUN: CM4 will reboot on RTC interruption GL-EN: CM4 power down on RTC interruption D17: D17 pin is triggered on RTC interruption (default) IO-VREF selection set the CM4 IO logic level as 3.3V (default) or 1.8V FAN power supply selection select 12V (default) or 5V power to drive the fan System function configuration BT_DIS: Bluetooth disabled, for CM4 with antenna variant ONLY WiFi_DIS: WiFi disabled, for CM4 with antenna variant ONLY WP_DIS: boot mode switch, ONLY be used when NOT booted from eMMC or SD card RTC/FAN I2C bus selection SDA0/SCL0: I2C-10 is shared with CSI/DSI (default) GPIO3/2: I2C-1 is shared with GPIO header Partial GPIO header including 1x I2C, 2x GPIO pins, and power supply UPS Module Mini header Product Show Outline Dimensions Resources & Services PACKAGE CONTENT Weight: 0.213 kg Package Contains CM4-IO-WIRELESS-BASE-B x1 Screwdriver x1 OPTIONS 4G module SIM7600G-H-M.2 x1 12V 2A power adapter x1 PCB antenna (IPEX connector) x1 Screws pack x1
